Two factor authentication for Remote Desktop (RDP) and Local Windows Logon

Overview

The LoginTC Windows Logon and RDP Connector integrates natively with Windows Server and Windows Client operating systems to add two-factor authentication for both remote desktop and local logins. LoginTC Windows Two-Factor Authentication solution adds an additional layer of security.

If you would like to protect your RD Web Access then you may be interested in the: LoginTC RD Web Access Connector.

If you would like to protect just your RD Gateway without protecting RD Web Access then you may be interested in the: LoginTC RD Gateway with RADIUS Connector.

Subscription Requirement
Your organization requires the Business or Enterprise plan to use the LoginTC Windows Logon and RDP Connector. See the Pricing page for more information about subscription options.

User Experience

After entering the username and password, the user is shown a selection of second factor options. The user clicks a button to receive a LoginTC push notification, authenticates and is logged in.

How MFA for Windows Works
Architecture

Windows 2FA/MFA Flow

  1. A user attempts access with username / password
  2. The username / password is verified against an existing first factor directory (i.e. Active Directory)
  3. An authentication request is made to LoginTC Cloud Services
  4. Secure push notification request sent to the user’s mobile or desktop device
  5. User response (approval or denial of request) sent to LoginTC Cloud Services
  6. The LoginTC Windows Logon and RDP Connector validates the user response
  7. User is granted access to Windows laptop / desktop

Prefer Reading a PDF?
Download a PDF file with configuration instructions:

System Requirements for LoginTC Two Factor Authentication (2FA/MFA)

Supported Windows Server versions:

  • Windows Server 2012 R2
  • Windows Server 2016
  • Windows Server 2019
  • Windows Server 2022

Supported Windows Client versions:

  • Windows 8.1
  • Windows 10
  • Windows 11

Additional Requirements:

  • LoginTC Admin account
  • .NET Framework 4.6.1 or higher
  • x64 architecture

Non-x64 architecture
LoginTC Windows Logon and RDP Connector is only compatible with x64 architecture systems. It will not run on systems, for example, that use ARM processors.

Create Application for Windows Logon 2FA/MFA

Start by creating a LoginTC Application for your Windows 2FA. An Application represents a service (e.g. RDP access to your Windows infrastructure) that you want to protect with LoginTC.

Create a LoginTC Application in LoginTC Admin, follow Create Application Steps.

If you have already created a LoginTC Application for your Windows 2FA, then you may skip this section and proceed to Installation.

Normalize Usernames
Windows usernames are in the form “CORP\john.doe”, while in the LoginTC Admin Panel it is generally more convenient to simply use “john.doe”.

Configure Normalize Usernames from the Application settings by navigating to Applications > Your Application > Settings.

Select Yes, Normalize Usernames scroll down and click Update.

Windows Installer

Install the LoginTC Windows Logon and RDP Connector.

  1. Download the latest version of the LoginTC Windows Logon and RDP Connector
  2. Run the installer file as a privileged administrator user.
  3. Press Next.
  4. Read the License Agreement and press Next if you accept the terms.
  5. Change the LoginTC API Host only if you have a private enterprise LoginTC deployment. Press Next:
  6. Enter your LoginTC Application ID and Application API Key. These values are found on your LoginTC Admin Panel (see Managing your Application. Press Next.
  7. Choose which logon types should be prompted for LoginTC. Press **Next**.

    Protecting Local Logons
    Note: After restarting the Windows host the LoginTC Windows Logon and RDP Connector will be fully installed and operational. See Which Windows logon prompts does LoginTC protect? for more information.

  8. Press Install.
  9. Press Finish

The LoginTC Windows Logon and RDP Connector is now installed. It will start protecting logins once the Windows host is restarted.

Usage

Your users may login in several ways. This chapter details the user experience for each interaction.

RDP Login

When a user launches their RDP client they will be presented with the standard login sequence. After successfully logging in with their username and password, they are shown the LoginTC login page on the remote host. Vadious login options for the second-factor LoginTC authentication are presented. Once successfully authenticated with LoginTC the user is logged into the host.

Local Logon

After successfully logging in with their username and password, they are shown the LoginTC login page on the local host. Vadious login options for the second-factor LoginTC authentication are presented. Once successfully authenticated with LoginTC the user is logged into the host.

Offline Logon

If the host does not have internet connectivity then after successfully logging in with their username and password, the user is shown options for logging in offline.

There are three methods of offline authentication:

  1. QR Scan Authentication. The user launches the LoginTC App, select Settings > Scan QR Code and then scan the displayed QR Code. If the scan is successful a 6-digit code is displayed for the user to enter and authenticate. QR Scan Authentication is only supported for LoginTC iOS App and LoginTC Android App.
  2. Passcode Grid. The user enters the 3-letter tuples corresponding to their own passcode grid. If the response is accurate they are are logged in. To learn more see: Passcode Grids.
  3. Offline Security Key. The user can insert a Security Key and press it to authenticate. If the security key is the right one they are are logged in. To learn more see: Security Keys.
  4. Offline Bypass Code. The user must enter a 9-digit Offline Bypass Code which is provided to them by their support desk. Codes are regenerated each time the user logs in online and can be found on the users page in the LoginTC Admin Panel under Offline Bypass Codes.

Must login online prior to offline methods being available
Offline methods are online available if the user has logged in online at least once. If the users token or passcode gird is revoked and re-issued, QR Scan and Passcode Grid Authentication will only be displayed after again logging in online at least once.


Policies
Offline authentication methods must be enabled in the relevant policy, see: Offline Authentication.

UAC (Run as administrator)

When LoginTC for UAC is enabled, the user requesting elevated privileges is prompted to authenticate with LoginTC:

  1. User right clicks on an application and clicks on Run as administrator
  2. User is prompted to enter the credentials of an administrator
  3. User is prompted to perform LoginTC authentication for that particular administrator

UAC Limitations
A LoginTC prompt is not prompted for the following scenarios: Run as different user; commandlets such as Enter-PSSession, Invoke-Command, and Get-Credential

Remembered Devices

Enforce a policy to allow a Windows device to be remembered for specified duration until the user signs out of their machine, reboots, logs in offline or changes networks. This feature applies to console unlock logons.

Remembered devices also works for offline logons.

Policies
Remembered Devices must be enabled in the authentication Policy. Navigate to Policies then your policy (or Organization Policy for global coverage). Scroll down to Remembered Devices to enable.

Command line Installation

You may also install the LoginTC Windows Logon and RDP Connector from the Command Prompt. This is particularly useful when deploying to a large number of machines.

To install from the Command Prompt:

  1. Find the Command Prompt in the Start menu
  2. Right Click and select “Run as administrator”
  3. Enter the following command (refer to the table below for configuration options)
msiexec /qn /i logintc-windows-logon-connector-1.2.0.0.msi CONFLOGINTCAPIHOST="cloud.logintc.com" CONFLOGINTCAPPLICATIONID="YOUR_APPLICATION_ID" CONFLOGINTCAPPLICATIONAPIKEY="YOUR_APPLICATION_API_KEY" CONFENABLERDP="1" CONFENABLECONSOLE="0" CONFENABLEUAC="0" CONFBYPASSUSERS=".\support,.\localadmin"
Flag Meaning Example
CONFLOGINTCAPIHOST The LoginTC API host cloud.logintc.com
CONFLOGINTCAPPLICATIONID The 40-character Application ID (found in the Admin Panel) 5de7c5b82a6972...
CONFLOGINTCAPPLICATIONAPIKEY The 64-character Applicatoin API Key (found in the Admin Panel) 5R2EgzXBOHx3RN...
CONFENABLERDP 1 to enable LoginTC for remote (RDP) logins, or 0 for all logins 1
CONFENABLECONSOLE 1 to enable LoginTC for console logins (or 0 to disable) 0
CONFENABLEUAC 1 to enable LoginTC for UAC (or 0 to disable) 0
CONFCHALLENGEGROUPS (Optional) Groups whose members will be challenged. Refer to Challenge Groups section for more information. RemoteMFAUsers
CONFBYPASSGROUPS (Optional) Groups whose members will be bypassed. Refer to Bypass Groups section for more information. RemoteMFAUsers
CONFCHALLENGEUSERS (Optional) Users which will be challenged. Refer to Challenge Users section for more information. *\support
CONFBYPASSUSERS (Optional) Users which will be bypassed. Refer to Bypass Users section for more information. *\support
Logging

The LoginTC Windows Logon and RDP Connector logs events to the Microsoft Event Viewer under Applications and Service Logs → LoginTC. LoginTC Windows Logon and RDP Connector event logs are helpful in debugging issues.

Passthrough

There are several ways to specify which set of users should be challenged with LoginTC second-factor authentication, and which ones will not. This is often useful when testing and when rolling out a deployment to minimize the impact on others or to maintain operational access to the hosts. Bypass settings are configured on each host where the LoginTC Connector is installed for your Windows multi-factor authentication (2FA/MFA).

Challenge Groups

The ChallengeGroups attribute is a comma delimited of groups for which all member users will be challenged with LoginTC second factor authentication. When either ChallengeGroups or ChallengeUsers is specified both BypassGroups and BypassUsers is ignored. If the user is not part of any challenge group, they are logged in without LoginTC two factor authentication (2FA/MFA).

Using Active Directory Groups
Note: Some groups cannot be retrieved by the LoginTC Windows Logon Connector like Remote Interactive LogonHigh Mandatory Level and similar Special Identities and non-Active Directory based groups. Recommend using only groups defined and managed in Active Directory.

Offline Active Directory Groups
Note: Security identifiers (SIDs) should be used for Challenge and Bypass groups instead of group names when the machine is expected to be used offline (or when the Active Directory domain controllers are expected to be unreachable).

Instructions to set ChallengeGroups attribute:

  1. Launch regedit (Registry Editor).
  2. Navigate to HKEY_LOCAL_MACHINE > SOFTWARE > Cyphercor > LoginTC Windows Logon Connector
  3. Click to modify the ChallengeGroups field
  4. Enter a comma delimited list of challenge groups, see format:
Format Meaning Example
*\groupname All groups part of any domain that have name groupname. *\RemoteMFAUsers
DOMAIN\groupname Groups with name groupname belonging to DOMAIN domain. DOMAIN\RemoteMFAUsers
groupname Local group with name groupname. RemoteMFAUsers
SID Group security identifiers (SIDs) S-1-5-21-...
  1. Click OK to save changes.

Bypass Groups

The BypassGroups attribute is a comma delimited of groups for which all member users will not be challenged with LoginTC second factor authentication. When either ChallengeGroups or ChallengeUsers is specified both BypassGroups and BypassUsers is ignored. If the user is not part of any bypass group, they are challenged with LoginTC second factor authentication.

Using Active Directory Groups
Note: Some groups cannot be retrieved by the LoginTC Windows Logon Connector like Remote Interactive LogonHigh Mandatory Level and similar Special Identities and non-Active Directory based groups. Recommend using only groups defined and managed in Active Directory.

Offline Active Directory Groups
Note: Security identifiers (SIDs) should be used for Challenge and Bypass groups instead of group names when the machine is expected to be used offline (or when the Active Directory domain controllers are expected to be unreachable).

Instructions to set ChallengeGroups attribute:

  1. Launch regedit (Registry Editor).
  2. Navigate to HKEY_LOCAL_MACHINE > SOFTWARE > Cyphercor > LoginTC Windows Logon Connector
  3. Click to modify the BypassGroups field
  4. Enter a comma delimited list of bypass groups, see format:
Format Meaning Example
*\groupname All groups part of any domain that have name groupname. *\RemoteMFAUsers
DOMAIN\groupname Groups with name groupname belonging to DOMAIN domain. DOMAIN\RemoteMFAUsers
groupname Local group with name groupname. RemoteMFAUsers
SID Group security identifiers (SIDs) S-1-5-21-...
  1. Click OK to save changes.

Challenge Users

The ChallengeUsers attribute is a comma delimited of users which will be challenged with LoginTC second factor authentication. When either ChallengeGroups or ChallengeUsers is specified both BypassGroups and BypassUsers is ignored. If the user does not match any challenge user, they are logged in without LoginTC two factor authentication (2FA/MFA).

Instructions to set ChallengeUsers attribute:

  1. Launch regedit (Registry Editor).
  2. Navigate to HKEY_LOCAL_MACHINE > SOFTWARE > Cyphercor > LoginTC Windows Logon Connector
  3. Click to modify the ChallengeUsers field
  4. Enter a comma delimited list of challenge users, see format:
Format Meaning Example
*\username All accounts, local or on any domain that have username username. *\john.doe
.\username Local account with username username. .\john.doe
DOMAIN\username Domain account with username username belonging to DOMAIN domain. CORP\john.doe
  1. Click OK to save changes.

Bypass Users

The BypassUsers attribute is a comma delimited of users which will not be challenged with LoginTC second factor authentication. When either ChallengeGroups or ChallengeUsers is specified both BypassGroups and BypassUsers is ignored. If the user does not match any bypass user, they are challenged with LoginTC two factor authentication (2FA/MFA).

Instructions to set BypassUsers attribute:

  1. Launch regedit (Registry Editor).
  2. Navigate to HKEY_LOCAL_MACHINE > SOFTWARE > Cyphercor > LoginTC Windows Logon Connector
  3. Click to modify the BypassUsers field
  4. Enter a comma delimited list of bypass users, see format:
Format Meaning Example
*\username All accounts, local or on any domain that have username username. *\john.doe
.\username Local account with username username. .\john.doe
DOMAIN\username Domain account with username username belonging to DOMAIN domain. CORP\john.doe
  1. Click OK to save changes.
FAQ

Which Windows logon prompts does LoginTC protect?

The LoginTC Windows two factor authentication (2FA/MFA) protects:

  • Remote Desktop Logins
  • Local Logins
  • Run as administrator

The LoginTC Windows two factor authentication (2FA/MFA) does not protect:

  • “Run as different user”
  • RDP Restricted Admin Mode
  • Pre-Logon Access Providers (PLAPs) such as Always On VPN
  • Noninteractive logins (e.g. batch process, mapping network drive, logon as a service, scheduled tasks)
  • PowerShell cmdlets: “Get-Credential”, “Enter-PsSession”, “Invoke-Command”

Does Windows logon work in Safe Mode?

By default, Windows disables all credential providers except the built-in password credential provider when in Safe Mode. If you wish to enable LoginTC in Safe Mode, you can do so by following these instructions:

  1. Open the Registry Editor
  2. Navigate to HKEY_LOCAL_MACHINE > SOFTWARE > Microsoft > Windows > CurrentVersion > Authentication > Credential Providers
  3. Create a key DWORD entry named ProhibitFallbacks with the value 1

Does the LoginTC Windows Logon and RDP Connector support Microsoft/Live accounts?

No, the connector does not support Microsoft/Live accounts.

Can the installer be deployed automatically?

Yes, commandline installation is supported: Command line installation

An end to end sample guide on deploying using Group Policy: Automatic LoginTC Windows Logon and RDP Connector Deployment.

Upgrade

To upgrade the LoginTC Windows Logon and RDP Connector, first uninstall the previous version and then install the newer version.

Uninstallation

To uninstall the LoginTC Windows Logon and RDP Connector, simply navigate to the Add or remove programs in the Windows Control Panel, find LoginTC Windows Logon and RDP Connector in the list and follow the prompts.

You may also uninstall the LoginTC Windows Logon and RDP Connector from the Command Prompt. This is particularly useful when deploying to a large number of machines.

To uninstall from the Command Prompt:

  1. Find the Command Prompt in the Start menu
  2. Right Click and select “Run as administrator”
  3. Enter the following command
msiexec /uninstall logintc-windows-logon-connector-1.0.3.0.msi /norestart /quiet

NOTE: The msi file has to be the same version that’s installed.

Troubleshooting

Email Support
For any additional help please email support@cyphercor.com. Expect a speedy reply.
